BS META
Esecuzione
Variable speed self-priming pressurisation system.
MÈTA is a plug-and-play solution, the pump is equipped with an integrated pressure transducer, an integrated check valve and a built-in pressure vessel.
The variable speed drive (VSD) controls the start and stop of the pump and allows to keep a constant pressure.
Applicazioni
For water supply.
For domestic use, gardening and irrigation.
Limiti impiego
Liquid temperature from 0 °C up to + 35 °.
Ambient temperature up to 40°C.
Maximum permissible pressure in the pump casing: 8 bar.
Continuous service.
Motore
2 pole induction motor
Nominal speed 4500 1/min (5800 1/min for MÈTA SMALL)
Engine speed: variable
Frequency: 50-60 Hz
Single phase 220-240V~50Hz/220V~60Hz, with thermoprotector
H07RN-F cable, 3G1.5 mm2, length 1.5 m, with CEI-UNEL 47166 plug
Class F insulation.
IP X4 protection.
Constructed in accordance to EN 60034-1, EN 60335-1, EN 60335-2-41.
